Tubing:N80 straight connection oil well tubing,sulfur-resistant oil pipe for drilling,T95 short connection,seal thread straight connection tubing,no coupling,1.9'tubing,NUE

Product Introduction of Oil Tubing byTianjin Grand Victory Petroleum Equipment Co.,Ltd

Tubing Coupling

Normally tubing coupling OD maximum is 4 1/2”, as the tubing pipe is applied for the drilling activities (Inside the tubing is the sucker rod to drill/pump the oil), couplings type is more various and rigorous than casing, mostly used is thicken type upset coupling (Internal upset and external upset), for short is EUE coupling, it is the most favorable in tubing connections. Tubing with EU end (EUE) coupling connection also called UPTBG. Because of the end of the tubing is thickened (upset), the connecting stress is better than buttress coupling.

Buttress coupling another type used for tubing connections, it has the same thickness of the pipe body, called NU end (NUE)tubing or TBG.

Features

The oil tubing coupling can solve the problem of fatigue fracture in the existing coupling due to stress concentration. Oil tubing end is connected to the inside wall of the coupling in a tapered thread. The coupling body end and oil tubing are connected with same thread pitch flat thread. The coupling is not easy to produce fatigue fracture, and has good connection effect. It can prevent the accident of oil well pipe string break effectively.

Casing Coupling

Casing coupling is for the dimensions more than 4 1/2 inch. Differently than tubing coupling is, casing coupling normally does not need to be thickened (Non-upset), which means no upset casing coupling, so it has following types:

• BTC: Buttress coupling

• LTC: Long buttress coupling

• STC: Short buttress coupling

All three types has same thickness of the casing pipe body, just have different lengths.

The oil casing coupling is a necessary piece used to connect the two casing. The coupling manufacturing method is the same as seamless pipe. The steel pipe ends with internal thread to connect with the upper and lower casing. In order to ensure the joint tightness, the precision of screw thread is strictly required.

If you have any Inquiry, please don't hesitate to contact us immediately.

Company’s Unique Advantages:

1.   Seamless Integration of Production and Sales: Our scientific management allows for flexible production scheduling. Since we focus on doing one thing exceptionally well, our production is entirely aligned with order timelines, making it easier to implement the planned arrangements.

2.   Comprehensive Range of Special Couplings at Lower Prices: We possess multiple coupling design authorizations and have a wealth of experienced workers, enabling us to produce couplings that meet various user requirements at a lower cost. This includes designs such as VAM, HYD511, OTTM, CBS3, 3SB, HSM2, and more.

3.   Industry-Wide Recognition: Over the past 17 years, our integrity, quality, and advantages have earned us an excellent reputation in the industry, which can be verified at any time.
