AFR-200 Small Gauge PTFE Wrapped Copper Hook-up Wire

Product

Posting date : Jun 04, 2026

Click enlarge Image

Membership

Free Member Scince May 21, 2026

FOB Price

$1.33/ m

Min. Order Quantity

1000 meter

Supply Abillity

1000000meter

Port

Shanghai

Payment Terms

EXW

Package

strand

Keyword :

PTFE wrapped wire

Product Introduction

AFR-200 is thin-wall small cross-section hook-up wire with PTFE film wrapped insulation, rated for 250V AC continuous operation and long-term working temperature up to 200°C.

Constructed with stranded high-purity fine copper conductor complying with GJB 1640 standard, this wire is designed for electrical & electronic equipment whose ambient or component temperature stays within 200°C, as well as circuits prone to overload current and heavy mechanical compression. It is the ideal internal wiring for compact, weight-sensitive instruments and electronic devices thanks to outstanding flexibility, repeated bending resistance and anti-vibration property. Its PTFE insulation can withstand high soldering iron heat without shrinkage or melting during welding assembly.

Core Basic Electrical Spec

Rated Voltage: 250V AC
Operating Temperature Range: -60℃ ~ +200℃
Insulation Resistance: ≥1.5×10⁶ MΩ·m at 20℃
Available Colors: Black, Brown, Red, Orange, Yellow, Green, Blue, Purple, Gray, White, Transparent or custom specified hues & stripe colors

Key Product Features

✅ High Dielectric Strength & Arc Resistance: Premium PTFE insulation delivers excellent breakdown voltage and superior anti-arc performance.

✅ Extreme Wide Temperature Tolerance: Continuous service from -190℃ to +250℃ without deterioration of insulation; withstand short-time peak up to 300℃, self-extinguishing once away from open flame (non-flammable).

✅ Outstanding Chemical Inertness: Resistant to nearly all organic solvents & most corrosive chemicals; only attacked by molten alkali metals, strong fluorinating agents, ensuring reliable corrosion resistance.

✅ Superior Weather & Aging Resistance: Zero water absorption, excellent UV & oxygen stability, long service life under harsh outdoor & high-temperature environments.

✅ High Flexibility & Mechanical Durability: Fine stranded copper construction for superb flex & anti-fatigue performance, perfect for tight-space routing inside precision equipment.

Full Technical Dimension & Electrical Parameter Table

Model	Cross Section (mm²)	Conductor Construction	Nominal OD (mm)	Max DC Resistance (Ω/km)	Weight (g/m)
AFR-200	0.014	7/0.05	0.41	1400	0.37
AFR-200	0.035	7/0.08	0.45	520	0.56
AFR-200	0.05	10/0.08	0.50	370	0.73
AFR-200	0.07	14/0.08	0.56	260	0.96
AFR-200	0.095	19/0.08	0.61	190	1.22
AFR-200	0.106	21/0.08	0.64	180	1.33
AFR-200	0.12	24/0.08	0.66	165	1.48
AFR-200	0.14	28/0.08	0.75	140	1.81
AFR-200	0.15	30/0.08	0.78	125	1.96
AFR-200	0.21	42/0.08	0.88	100	2.60
AFR-200	0.26	52/0.08	0.95	90	3.11
AFR-200	0.31	62/0.08	1.01	70	3.61
AFR-200	0.38	75/0.08	1.08	60	4.26
AFR-200	0.42	85/0.08	1.13	55	4.76
AFR-200	0.47	95/0.08	1.17	50	5.05
AFR-200	0.52	105/0.08	1.23	42	5.75
AFR-200	0.75	150/0.08	1.41	23	7.94
AFR-200	1.00	210/0.08	1.68	18	10.88
AFR-200	1.20	240/0.08	1.76	15	12.55

Typical Application Scope

Internal wiring for precision instruments, analytical meters, laboratory testing equipment
High-temperature control & internal wiring of industrial electrical appliances, aerospace small electronic modules
Compact electronic devices, sensor internal leads, wiring under overload & high mechanical compression working conditions
