ONN M4B-50 LED Warning Light
0 likes
China [CN] ONN-M4B LED Warning Light
Introduction:
1. Hemispheric design, elegant appearance.
2. Aluminum body with PC cover makes it sturdy and durable.
3. Three colors on a single layer, easy to distinguish
different signals.
4. Easy to install.
5. M12 connector wiring is optional.
Application: CNC machine, Automatic equipment,
SMT equipment etc, Production line.
Warranty:
2 years
Certification: CE, RoHS, FCC
Ordering code:
ONN - M4B 1 B B T RYG 50 | |
1 3 4 5 6 7 | |
1.Layer | 1: Single layer |
2. Voltage | A: DC12V B: DC24V |
3.Function | B: Steady, S: Red flash, D: All flash F: Steady with buzzer C: Red flash with buzzer E: All flash with buzzer |
4.Connect type | C: Contact type, T: PNP& NPN |
5. Color | R: Red, Y: Yellow, G:Green |
7. Diameter | 50: φ50mm |
Parameter:
Full Power | 3W |
Input voltage | DC12V DC24V |
Input current | 30 to 50mA for each color |
Working Temperature | -20~45℃ |
IP rating | IP65(No buzzer) IP30(Buzzer type) |
Buzzer volume | 85dB |
Material | Aluminum body and PC cover |
Lifetime | 50,000 hours |
Installation | Fixed by thread |
Click enlarge Image
