Aerospace material simulation thermotron altitude chamber
0 likes
China [CN] High altitude (low pressure) simulation: By controlling the air pressure inside the test chamber, it can simulate high-altitude or space vacuum environments, suitable for performance verification of aerospace equipment and electronic devices for high-altitude use.
Parameters such as test temperature (-70℃ - 150℃), humidity (10%-98% RH), vibration (sine/random) can reproduce extreme environmental combinations, such as the impact of "high temperature + low pressure + vibration" on aircraft components. Application scenario
Aerospace field: Testing the reliability of aircraft avionics equipment under high-altitude, low-temperature and low-pressure conditions;
Military industry field: Simulating the stability of weapons equipment in plateau and high-altitude battlefield environments.
Aerospace field: Verifying the thermal control system of satellites' thermal balance ability in the vacuum environment of space;If you need more information about the models of our testing equipment. Please contact me.https://www.chamber-testing.com/a/d/TVAC-Thermal-Vacuum-Test-Chamber.html
Technical Specifications Capacity：0.5 m³ to 2.65 m³(Customizable) High Vacuum Level (mbar)：5.0×10−7 No-load Vacuum Level (mbar)：5.0×10−7(Room temperature) Vacuum Cube Leak Rate：1×10−9std/cc/sec Pressure Regulation in Multiple Ranges (mbar/Torr)：Adjustable Temperature Range： -190°C(LN2 cooling) to 150°C Temperature Uniformity：±2℃
