1.0 Meter Movable Ground Station for TT&C
0 likes
Hong Kong [HK] | G/T(dB) | ≥2.60+20lg(F/F0),F0=2200MHz ≥14.3+20lg(F/F0),F0=8400MHz |
| EIRP(dBW)(50W SSPA) | ≥40.8+20lg(F/F0),F0=2025MHz ≥51.7+20lg(F/F0),F0=7120MHz |
| Power consume(W) | ≤720 |
| Weight(Kg) | ≤80.5 |
| Data rate(QPSK) | ≤25Mbps |
Note:For Ku,Ka,QV band, can be negotiated
1.0m system configuration
| No | EQ Name | Number | Note |
| S band Feed | 1 | ||
| X band Feed | 1 | ||
| Antenna reflector | 1 | 7/9 valves | |
| XY type turning system | 1 | ||
| tripod | 1 | ||
| lithium battery | 1 | ||
| S band LNA | 1 | ||
| X band LNA | 1 | ||
| S band BUC | 1 | ||
| X band BUC | 1 | ||
| X band converter | 1 | ||
| BBE | 1 | TTC and data revceiver | |
| MCS | 1 | Computer+software | |
| Cables | 1 set | ||
| GPS | 1 | ||
| switch | 1 | ||
| Box | 1 | ||
| knapsack | 2 |
