China [CN] The SG61000-5 fully automatic surge generator (also called lightning surge immunity test, combination wave generator, surge current generator/surge voltage generator, combined surge voltage and current generator) .
4.8KV or 6KV Surge Generator SG61000-5
How does a surge generator work?
The SG61000-5 surge generator provides a common basis for evaluating the resistance of power cords and internal connectors of different equipment to high energy transient interference caused by natural lightning surge induction and large capacity load switching. It fully meets the IEC 61000-4-5, EN61000-4-5 and GB/T17626.5 standards.
Specifications:
| Product Model | SG61000-5SA | SG61000-5SB | SG61000-5 | SG61000-5H-SP | SG61000-5T |
| Output Voltage (Open) | 1.2/50μs±20% | 1.2/50μs±20% | 1.2/50μs±20% | 1.2/50μs±20% | 1.2/50μs±20% |
| Output Current (Short) | 8/20μs±20% | 8/20μs±20% | 8/20μs±20% | 8/20μs±20% | 8/20μs±20% |
| Output Impedance | 2Ω and 12Ω | 2Ω and 12Ω | 2Ω and 12Ω | 2Ω 12Ω and 500Ω | 2Ω and 12Ω |
| Output Voltage Range | 0~4.8KV±10% | 0~4.8KV±10% | 0~6KV±10% | 0~10KV±10% | 0~6KV±10% |
| Output Current Range | 0~2.4KA±10% | 0~2.4KA±10% | 0~3KA±10% | 0~5KA±10% | 0~3KA±10% |
| Surge Repetition | 1~9999 times | 1~9999 times | 1~9999 times | 1~9999 times | 1~9999 times |
| Interval Time | 20~9999s | 20~9999s | 20~9999s | 30~9999s | 20~9999s |
| Polarity | Positive, Negative or Positive/Negative automatic | ||||
| Phase Shift | Asynchronous, Synchronization 0°~ 360° or Specific Angle | ||||
| Special Function | N/A | Built-in High voltage and current 2000:1 attenuator probe (Less than 10KV surge generator is 1000:1), connect with LISUN OSP1102 directly | |||
| Operation Way | Button Input | Touch screen with super big LCD and built-in Windows CE | |||
| Dimensions (WxDxH) | 44x45x35cm | 44x45x35cm | 44x45x35cm | 56x69x155cm | 44x45x55cm |
| Gross Weight | About 30kg | About 30kg | About 30kg | About 270kg | About 48kg |
| Coupling/Decoupling Network (CDN) | Includes a 16A single phase CDN | Includes a 20A 3phases CDN | |||
| Isolution Transformer for EUT (Optional) | LISUN ITEU-SP4K (220V Single phase) or ITUS-SP2K (110V) | LISUN ITEU-TP10K or ITUS-TP5K | |||
Over 10KV Surge Generator SG61000-5H
Remark: 10KV Surge Generator, 12KV Surge Generator, 15KV Surge Generator, 20KV Surge Generator and any other higher voltage Surge Generator can be designed according to your requirement.
Due to the high voltage risk during the Surge Test, we suggest you to option choose the Protect Device for Surge Test PD-E01 to together work with Surge Generator SG61000-5 (The PD-E01 inside size is 30*30*30cm for EUT, other size need to special design)
Protect Device for Surge Test PD-E01
We suggest you choose LISUN SG-DESK Surge Generator desk to work with SG61000-5 Surge Generator and Isolation Transformer.
SG-DESK Surge Generator Desk
What is a combination wave?
A Combination Wave Generator (CWG) sends a voltage impulse into an open circuit while also delivering a current impulse into a short circuit to mimic both of these situations. The SG61000-5 Surge Generator’s combination wave is 1.2/50us and 8/20us as below:
6KV Short Circuit Current Output Waveform (780:1) 6KV Open Circuit Voltage Output Waveform (1000:1)
LISUN SG61000-5 Surge Generator – After Sales Questions and Answers.
LISUN SG61000-5 Surge Generator were in the market for more than 10 years, LISUN engineers service team already summary the most of the After Sales Questions and Answers in the above link. Please read it carefuly, you can solve the most of the problems by yourself if you have some questions while using the instruments. LISUN will be continue to update this pages and more FAQ can be found in this topic link.
