SQUARE KNOTS FIELD FENCES
0 likes
China [CN] Square Knot Field Fence has s-shaped knots to form a tough & sturdy structure that stands up to impact from large animals without buckling or sagging. It is a type of anti climbing fence, suitable for goat, sheep and cattle keeping, commonly known as S knot fence.
S knot fence is made with a separate piece of wire to attach the line wire to the solid stay wire forming an impact resistant and very smooth knotted ring, ideal for the protection of livestock’s skin and strong enough to feeding animals.
Illustration of S knot structure
Square S Knot Forming, Illustrated from Both Front View and Rear View
Hot dipped Galvanized S Knot Field Fence
Material: high tensile wire
inner wire: 2.0mm,2.5mm or others
Color: silver or others
Mesh size: 10cm,15cm,30cm
Knot style: square deal knot
Hole shape: Rectangular
Wire gauge: 1.8mm-2.5mm
Surface: galvanized bright
Edge wire diameter: 2.0mm-3.2mm
zinc coating: 30-300g/square meter
Square Knot Field Fence - Cow security fence export to Australia,New Zealand, USA.
Square Knots Field Fencing for Cattles
Woven wire field fence with the Square Deal knot offers rigid performance which help keep its shape over hilly ground. Square Deal Field Fence comes in multiple heights, styles, and gauges designed to meet customers particular needs. We supply modular fence and fence meeting with specific requirements.
Common Specifications of Square Knots Fencing:
| Item Number | Approx. Wt./roll | Fabric Height (in.) | Roll Lenght (ft.) | Filler Wire Gauge | Top Wire Gauge | Bottom Wire Gauge |
| S-1 | 260 | 39 | 330 | 9 | 9 | 9 |
| S-2 | 276 | 49 | 330 | 9 | 9 | 9 |
| S-3 | 295 | 47 | 330 | 9 | 9 | 9 |
| S-4 | 202 | 32 | 339 | 11 | 9 | 9 |
| S-5 | 232 | 39 | 330 | 11 | 9 | 9 |
| S-6 | 264 | 47 | 330 | 11 | 9 | 9 |
| S-7 | 181 | 39 | 330 | 11 | 9 | 9 |
| S-8 | 201 | 47 | 330 | 11 | 9 | 9 |
| S-9 | 141 | 32 | 330 | 12 | 10 | 10 |
| S-10 | 161 | 39 | 330 | 12 | 10 | 10 |
| S-11 | 183 | 47 | 330 | 12 | 10 | 10 |
