High Vacuum Transformer Oil Filtration Machine
Posting date : Sep 13, 2021
Membership
Free Member Scince Sep 09, 2020
FOB Price
USD 10,000.00 ~ 30,000.00
Min. Order Quantity
1 SET
Supply Abillity
50 SETS/Month
Port
Shanghai
Payment Terms
T/T, L/C
Package
wooden cases for sea freight
Keyword :
Category
Contact
Kevin Hu
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
PURETECH
Model Number
DVOP
HS-CODE
8421-29
Package & Delivery Lead Time
Package
wooden cases for sea freight
Delivery Lead Time
15 ~ 20 working days
Detailed Description

Application of Transformer Oil Filtration Machine

The PureTech Oil Filtration mobile Double-Stage High Vacuum Transformer Oil Purifiers (Model DVOP) are used for transformer oil dehydration, degasification and filtration. As a necessary maintenance tool for power transformers, it can effectively remove free and soluble water, gases and particulate matters contained in the transformer oil, thereby increasing and maintaining the dielectric strength of transformer oil, performing good insulation function in power transformers.

Double-Stage High Vacuum Transformer Oil Purifiers (Model DVOP) adopt two-stage vacuum pumps, namely rotary vane vacuum pump and roots booster vacuum pump, they are especially applied to transformer oil treatment of 110KV,220KV,500KV,750KV,1000KV power transmission line.

In addition, Model DVOP can also be used as an vacuum drying and vacuum filling equipment during transformer maintenance.



Features of Transformer Oil Filtration Machine

• Double-stage high vacuum improve the effect and efficiency of oil dehydration and degasification.

• Multi-stage filtration ensures the high oil filtering accuracy.

• Multifunctional integrated equipment, can be used oil treatment, vacuum oil filling and vacuum drying.  (*More functions can be customized according to your requirements.)

• The uniquely designed “T” vacuum chamber enlarges the oil evaporation area more than the traditional design, so as to achieve a better dehydration and degassing effect.

• Model DVOP Transformer Oil Purifier can work offline or online under the safe operation.

• A regeneration device can be mounted or connected on its basis for transformer oil regeneration.

• Online oil testers, trailer type with road-worthy wheels, weather-proof enclosure and other spare parts are available for selection.

 Operation of transformer oil filtration machine is easy and stable.


Technical Parameters of Transformer Oil Filtration Machine

Machine Parameter

ItemUnitDVOP-30DVOP-50DVOP-75DVOP-100DVOP-150DVOP-200DVOP-300
Flow rateliters/hour180030004500600090001200018000
Vacuum degreeMpa(-0.08) ~ (-0.099)
Working pressureMpa≤ 0.3
Temperature range40 ~ 80
Power supply380Volts, 50Hz, 3Phase (Or customized)
Heating powerkw2430486090120130
Total powerkw26345468100135146
Inlet/outlet diametermm32324444505865
SizeLengthmm1250135015501800200021002300
Widthmm900100011501400175018502000
Heightmm1450150017001750180022502300
Weightkg5006008001100130019002300
Oil index after purificationBreakdown voltagekV≥75 (Spherical electrodes)
Water contentppm≤5
Gas content%≤0.1
Filtering accuracymicron1

OPTIONAL CONFIGURATIONS: PLC automatic control system, Fully-Touch Screen, Mobile Trailer, Weather-proof Enclosure, Online Oil Testing Instruments, etc.

* Please inquire us for other flow rates or types.

* The machine size and weight will change slightly due to different configurations.


PureTech Successful Projects on Oil Purification

https://youtu.be/ges3R__nkTc
