Anti Rust 3003 HO Flex Pipe 1.0mm Aluminum Strip Coil 60mm Width

Product

Posting date : Feb 24, 2021

Click enlarge Image

Membership

Free Member Scince Feb 24, 2021

FOB Price

Min. Order Quantity

Supply Abillity

Port

Payment Terms

Package

Keyword :

Aluminum Strip Coil

Category

METALS | Aluminum a | Aluminium | Aluminium

Contact

Wang

0 likes

Product Detail

Company Info

Quick Detail

Place of Origin

China [CN]

Brand Name

HS-CODE

7607-11

Package & Delivery Lead Time

Package

Detailed Description

Product Description

3003 HO Aluminum Strip For Flex Pipe coil 1.0mm aluminum divider strip

Name : Latest technology aluminum cutter strip for foil tile trim aluminum 60mm strips

Aluminum Strip Description

Aluminum Strip is a commonly used Al-Mn antirust alloy . Similarly , aluminum Strip is also a non-heat-treated alloy , and its mechanical properties can be improved by conventional cold processing . In addition to , because aluminum Strip has good corrosion resistance , plus excellent weldability , formability and other advantages , it is often used in packaging , mechanical components , refrigerators , air conditioning ventilation pipes , or ships , vehicles , pressure vessels and so on . Here , YONGSHENG ALUMINUM produces 3003 H14 aluminum Strip with smooth and fine surface , small thickness tolerance , good stamping and oxidation effect . Through testing , all indexes are far beyond the standard indexes , and the products are guaranteed !

Applications and Features :

1 . Corrosion Resistance .

The corrosion resistance of 3003 H14 aluminum Strip is better than that of 1 series aluminum coil , which can resist corrosion in atmosphere , fresh water, seawater , food , organic acid , gasoline , neutral inorganic salt water solution and dilute acid environment .

2 . Anodizing Property .

Since the color is not uniform after anodic oxidation , the 3003 H14 aluminum Strip is generally not anodized .

3. Other features.

In the annealed temper , the plasticity of the 3003 H14 aluminum Strip is very high . In the case of semi - cold hardening, the plasticity is good , while in the case of cold hardening , the plasticity is low . And good weldability , poor cutting performance , etc . The use of 3003 H14 aluminum Strip Typical Usages of 3003 H14 aluminum Strip : Wine bottle cap, Beverage bottle cap , Cosmetic bottle cap , Cell phone battery shell material , Lighting decoration , Interior decoration , Heat sink plate , Radiator , Power battery shell , Automobile heat shield , fuel tank , Water tank , Automobile anti - skateboard , Battery explosion-proof valve , Battery cover plate , Automobile interior , Signage , Cans , Medical equipment , etc .

If you want to know more about our Aluminum products or Aluminum Coil , please feel free to contact us , we will reply you within 24 hours .

Features of the 1 series :

It belongs to a series containing the most aluminum.Contains more than 99.00% aluminum, good electrical conductivity, good corrosion resistance, good welding performance, low strength.Used in conventional industry.

Features of the 2 series :

The hardness is high, in which the copper element content is the highest, about 3-5%. Mn, magnesium, lead and bismuth are also added for machinability.Used in the field of aviation.

Features of the 3 series :

It is mainly composed of manganese.The content is between 1.0% and 1.5%, used for industries and products with high requirements for rust prevention.Good corrosion resistance, good weldability and good plasticity.

Features of the 5 series :

It belongs to the series of commonly used alloy aluminum plate, the main element is magnesium.The main characteristics are low density, high tensile strength, high elongation, good fatigue strength, but can not be strengthened by heat treatment.It is also widely used in conventional industry.

Features of the 6 series :

Contains mainly magnesium and silicon, suitable for corrosion resistance, oxidation demanding applications.

Features of the 7 series :

It belongs to aeronautical series, aluminum magnesium zinc copper alloy, heat treatable alloy, super hard aluminum alloy, has good wear resistance, also has good weldability, but corrosion resistance is poor.

Alloy	State	Thickness(mm)	Tensile Strength(Mpa)	The Yield Strength(Mpa)	elongation(%)	hardness(HV)
1060 (1050)	0	>0.2-0.5	60-100	≥15	≥20	20-30
		>0.5-1.0			≥30
		>1.0-4.0			≥35
	H22	>0.2-0.5	80-120	≥60	≥12	30-40
		>0.5-1.0			≥15
		>1.0-4.0			≥18
	H24	>0.2-0.5	95-135	≥70	≥6	35-45
		>0.5-1.0			≥8
		>1.0-4.0			≥10
	H26	>0.2-0.5	110-155	≥75	≥2	43-55
		>0.5-1.0			≥4
		>1.0-4.0			≥6
	H18	>0.2-0.5	≥125	≥85	≥2	50-65
		>0.5-1.0			≥3
		>1.0-4.0			≥4
1100 (1200)	0	>0.2-0.5	75-105	≥25	≥18	25-30
		>0.5-1.0			≥30
		>1.0-4.0			≥35
	H22	>0.2-0.5	95-130	≥75	≥12	30-40
		>0.5-1.0			≥15
		>1.0-4.0			≥18
	H24	>0.2-0.5	110-145	≥95	≥6	38-40
		>0.5-1.0			≥8
		>1.0-4.0			≥10
	H26	>0.2-0.5	130-165	≥115	≥2	45-60
		>0.5-1.0			≥4
		>1.0-4.0			≥6
	H18	>0.2-0.5	≥150	≥130	≥2	55-70
		>0.5-1.0			≥3
		>1.0-4.0			≥4
3003 (3A21)	0	> 0.2-0.5	95-140	≥ 35	≥ 15	30-40
		> 0.5-1.0			≥ 30
		> 1.0-4.0			≥ 35
	H22	> 0.2-0.5	120-160	≥90	≥ 12	39-53
		> 0.5-1.0			≥ 15
		> 1.0-4.0			≥ 18
	H24	> 0.2-0.5	145-195	≥125	≥ 6	42-59
		> 0.5-1.0			≥ 8
		> 1.0-4.0			≥ 10
	H26	> 0.2-0.5	170-210	≥150	≥ 2	55-65
		> 0.5-1.0			≥ 4
		> 1.0-4.0			≥ 6
	H18	> 0.2-0.5	≥ 190	≥ 170	≥ 2	60-85
		> 0.5-1.0			≥ 3
		> 1.0-4.0			≥ 4
3004 (3104)	0	> 0.2-0.5	155-200	≥ 60	≥ 13	49-62
		> 0.5-1.0			≥ 16
		> 1.0-4.0			≥ 20
	H22	> 0.2-0.5	190-240	≥ 145	≥ 10	60-84
		> 0.5-1.0			≥ 12
		> 1.0-4.0			≥ 14
	H24	> 0.2-0.5	220-265	≥ 170	≥ 8	68-100
		> 0.5-1.0			≥ 10
		> 1.0-4.0			≥ 12
	H26	> 0.2-0.5	240-285	≥ 190	≥ 3	72-110
		> 0.5-1.0			≥ 4
		> 1.0-4.0			≥ 6
	H18	> 0.2-0.5	≥ 260	≥ 230	≥ 2	85-120
		> 0.5-1.0			≥ 2
		> 1.0-4.0			≥ 3
3005	0	>0.2-0.5	115-165	≥45	≥13	35-45
		>0.5-1.0			≥20
		>1.0-4.0			≥25
	H22	>0.2-0.5	145-195	≥110	≥10	40-60
		>0.5-1.0			≥15
		>1.0-4.0			≥15
	H24	>0.2-0.5	170-215	≥130	≥6	58-70
		>0.5-1.0			≥8
		>1.0-4.0			≥10
	H26	>0.2-0.5	195-240	≥160	≥3	65-83
		>0.5-1.0			≥4
		>1.0-4.0			≥6
	H18	>0.2-0.5	≥220	≥200	≥2	80-100
		>0.5-1.0			≥3
		>1.0-4.0			≥3
3105	0	>0.2-0.5	75-105	≥25	≥14	32-42
		>0.5-1.0			≥20
		>1.0-4.0			≥25
	H22	>0.2-0.5	95-130	≥75	≥10	39-60
		>0.5-1.0			≥12
		>1.0-4.0			≥12
	H24	>0.2-0.5	110-145	≥95	≥8	52-62
		>0.5-1.0			≥10
		>1.0-4.0			≥10
	H26	>0.2-0.5	130-165	≥115	≥3	58-72
		>0.5-1.0			≥4
		>1.0-4.0			≥6
	H18	>0.2-0.5	≥150	≥130	≥2	65-95
		>0.5-1.0			≥2
		>1.0-4.0			≥3
5005	0	>0.2-0.5	100-145	≥35	≥15	33-43
		>0.5-1.0			≥20
		>1.0-4.0			≥25
	H22	>0.2-0.5	125-165	≥80	≥12	30-53
		>0.5-1.0			≥15
		>1.0-4.0			≥18
	H24	>0.2-0.5	145-185	≥110	≥8	40-60
		>0.5-1.0			≥10
		>1.0-4.0			≥10
	H26	>0.2-0.5	165-205	≥135	≥3	50-68
		>0.5-1.0			≥4
		>1.0-4.0			≥6
	H18	>0.2-0.5	≥185	≥165	≥2	57-68
		>0.5-1.0			≥2
		>1.0-4.0			≥3
5052 (5251)	0	> 0.2-0.5	170 - 215	≥ 65	≥ 14	50 - 70
		> 0.5-1.0			≥ 17
		> 1.0-4.0			≥ 20
	H22	> 0.2-0.5	210 - 260	≥ 130	≥ 8	70 - 85
		> 0.5-1.0			≥ 10
		> 1.0-4.0			≥ 10
	H24	> 0.2-0.5	230 - 280	≥ 150	≥ 4	80 - 110
		> 0.5-1.0			≥ 6
		> 1.0-4.0			≥ 6
	H26	> 0.2-0.5	250 - 300	≥ 180	≥ 2	85 - 115
		> 0.5-1.0			≥ 4
		> 1.0-4.0			≥ 6
	H18	> 0.2-0.5	≥ 270	≥ 240	≥ 2
		> 0.5-1.0			≥ 2
		> 1.0-4.0			≥ 3

Aluminum Strip Technical Data

Alloy / Grade : 1000 Series , 2000 Series , 3000 Series , 5000 Series , 6000 Series , 7000 Series , 8000 Series
Temper : O - H112 , T3 - T8 , T351 - T851
Thickness : 0.13mm - 6.5mm
Width : 3mm - 2600mm
Length : As per your requirements
Size : Customized Size
Feature : Eco-friendly
Package : Wooden Pallets
Type : High Purity Aluminium Strip
Color : Silver
Shape : Alu Strip
Hardness:O/HO
Conductivity ( % IACS ) : ≥61.5
Elongation ( % ) : > 23
Tolerances : As per your requirements
Application : Industry , Decoration , Building , Packing , Pressing , Etc .
Surface treatment : Mill Finish , Coated , Powder Coated , Anodized , Polished mirror , Embossed , Etc .
Special Specification is available on customer ’ s requirement
Delivery time : 7-30 days after order confirmation
MOQ : 1 ton
Coil ID : As per your requirements

Aluminum Strip Use

Aluminum Strip for transformer ( aluminum foil for transformer )
Aluminum Strip for high-frequency welding hollow aluminum strip
Aluminum Strip for finned radiator
Aluminum Strip for cable
Aluminum Strip for stamping
Aluminum Strip for edge strip , etc .

Aluminum Alloy Belt Categories :

pure aluminum strip
transformer aluminum strip
super hard aluminum strip
all soft aluminum strip
semi hard aluminum strip
rust proof aluminum strip

Anti Rust 3003 HO Flex Pipe 1.0mm Aluminum Strip Coil 60mm Width 0

Anti Rust 3003 HO Flex Pipe 1.0mm Aluminum Strip Coil 60mm Width 2

FAQ

1. who are we?
Henan Yongsheng Aluminum Co. , Ltd . is located in Gongyi City Industrial Cluster Area , Henan Province . The factory focuses on the production and development of aluminum products such as Aluminum Strip , Color Aluminum , Aluminum Sheet , Aluminum Coil , Pressed Aluminum Product , Embossed Aluminum , and non-slip aluminum Sheet . The factory covers an area of 100 , 000 square meters , has 476 employees , has 20 casting processing production lines , 2 color coated aluminum coil production lines , 3 slitting production lines , 4 shearing production lines , 32 punch presses , 10 CNC lathes , 4 The embossed aluminum production line has an annual output of more than 200 , 000 tons , and exports account for more than 40 % .

2. how can we guarantee quality?

1 - we can provide samples . We can send the samples by TNT,DHL, FEDEX, EMS, UPS or to your warehouse .

2 - Always a pre-production sample before mass production .

3 - Always final Inspection before shipment .

3. How long will it take to execute my order?
Our normal produce time is 7-15 working days.

4. How much will the shipping cost be?
This will depend on the size and weight of your order and the method of shipping.

5. Do you have products in stock?
There are 10000 tons stock for various size .plsease inform us what model you need , we will send stock details to you .

6. why should you buy from us not from other suppliers?

1 - 20 years experience in aluminum industry .

2 - Source manufacturers, leading equipment, excellent team skills .

3 - Low price, fast delivery and excellent quality .

4 - Professional technical solution .

7. what services can we provide?

1 - Accepted Delivery Terms : FOB , CFR , CIF , EXW , CIP , CPT , DDP , DDU ；
