Flake Ice Machine 3T/24h,Flake Ice Machine 3T Supplier,Flake Ice Machine 3T Manufacturer

Product

Flake Ice Machine 3T/24h,Flake Ice Machine 3T Supplier,Flake Ice Machi...

Posting date : Aug 20, 2019

Click enlarge Image

Membership

Free Member Scince Jan 07, 2019

FOB Price

Min. Order Quantity

1set

Supply Abillity

10sets/day

Port

GuangZhou

Payment Terms

T/T,Wire transfer

Package

Wooden frame or wooden support

Keyword :

Flake Ice Machine 3T

Category

Contact

Li Huabin

0 likes

Product Detail

Company Info

Quick Detail

Place of Origin

China [CN]

Brand Name

DAKA FREEZER

HS-CODE

Package & Delivery Lead Time

Package

Wooden frame or wooden support

Delivery Lead Time

10-30days

Detailed Description

Flake Ice Machine 3T/24h,Flake Ice Machine 3T Supplier,Flake Ice Machine 3T Manufacturer

Flake Ice Machine 3T Supplier

Flake Ice Machine 3T Manufacturer

Share:Flake Ice Machine 3Ton Per Day

Fresh Water /Salt Water

Air Cooling/Water Cooling

Flake Ice Thickness: 1.5-2.2mm

Refrigerant: R22/R404A

With PLC Controller

Flake Ice Machine 3T/24H

DAKA FREEZER industry flake ice machines are mainly used in aquatic processing, chemical pigments, biological pharmacy

and scientific experiments etc. Ice production from 3t/d to 15t/d which can meet the industrial ice demand.

Advantages of the flake ice machine:

1. The ice machine has high ice efficiency and small loss of cooling capacity.

2. Good quality of the flake ice and is dry and not bonded.

3. The flake ice produced by the flake ice machine is rich in variety, simple in structure

4. PLC programmable controller of the flake ice machine, with stable performance, random control

5. The flake ice machine is easy to operate, high standard of hygiene

6.The flake ice machine with the perfect fault protection device.

Technical Parameters

Model	DFI-3T
Capacity	3000kg /24h
Necessory cooling capacity	18.5kW
Compressor Cooling capacity	22KW
Evaporating temp.	-20℃
Condensing temp.	40℃
Standard water temperature	20℃
Power install	13KW
Compressor	15HP 11KW
Reduction gear	0.18 KW
Cooling pump	1.1KW
Power supply	380V/50Hz/3P
Water pressure	0.1Mpa-0.5Mpa
Refrigerant	R404a
Ice temperature	-5℃
Water pipe	1/2’
Net weight	600kg
Machine size	170012001200mm
Ice bin Dimension(mm)	170020001500mm

DAKA FREEZER medium-size industry flake ice machine (ice production 3T/4T/5T/8T/10T/15T/24H)

1.Standard conditions: Ambient temperature 25℃, water inlet temperature 15℃, evaporating temperature -22℃, condensing temperature 40℃.

2. Thickness of the flake ice: 1.5mm-2.2mm,it can be adjustable.

3. The above parameters will be changed subject to the technical invotation without further notice.

Would you like some more information or to order your new machine….Email Us or call 86-20-81778146
