Constant Pressure Drilling Fluid Mud Gas Separator
0 likes
China [CN] Mud Gas Separator Used In Oilfield DESCRIPTION
Constant pressure drilling fluid mud gas separator is a specialized equipment used for primary degassing of gas-cutting drilling fluid,it is mainly used to remove big bubbles whose diameter ≥φ3mm.
Mud gas separators produced by DC have the advantages of safety and reliability,good treatment effect,long service life ,etc.
Constant pressure Anti-H2S drilling fluid mud gas separator manufactured by DC adopts high quality material , can effectively prevent the erosion of harmful gas and ensure production safety of man and machine.
Mud Gas Separator Parameters
Model | DCZYQ800 | DCZYQ1000 | DCZYQ1200 |
Treating capacity | 200~260m3/h | 240~300m3/h | 280~360m3/h |
Main body | 800mm | 1000mm | 1200mm |
Tank wall thickness | 10mm | 10mm | 12mm |
Inlet | 5" | 5" | 5" |
Outlet | 8" | 8" | 10" |
Vent-pipe | 8" | 8" | 8" |
Dimension | 1600×1600×5720mm | 2000×2000×5920mm | 2200×2200×6634mm |
Weight | 1600kg | 2100kg | 3200kg |
We provide Solid Control Equipment, drilling mud system, shaker screen and solids control equipment spare parts, include Submersible Slurry Pump, Drilling Cutting Box, Jet Mud Mixer, Vacuum,Degaaser, Decanter Centrifuge, Mud Gas Separator.Our products have high quality and competitive prices,Please click here to visit our website and learn more.
