very very rigid UHMWPE sheet , engineering plastic sheet /pad / board / panel from China

Waht is the UHMWPE sheet ?                                                                     very rigid UHMWPE sheet , engineering plastic sheet /pad / board / panel from China

UHMW-PE stands for Ultra High Molecular Weight Polyethylene. It is the highest quality polyethylene (PE) available, engineered for tough jobs and a wide range of applications. It delivers savings in a number of difficult applications. Ultra High Molecular Weight is the secret of this polymer’s unique properties. Its high-density polyethylene resin has a molecular weight range of 3 to 6 million, compared to 300,000 to 500,000 for high molecular weight (HMW) resins. That difference is what ensures that this material is strong enough to withstand abrasion and impact better than lower level poly products. UHMW-PE’s high molecular weight means it will not melt or flow as a molten liquid. Processing methods are therefore derived from those of powder metal technology. UHMW-PE cannot be transformed and molded by conventional plastic processing techniques (injection molding, blow molding or thermoforming). Compression molding is the most common conversion process used with this resin because it produces a stronger, more consistent product.

The featurer of UHMWPE sheet

1,Excellent wear resistance

UHMWPE sheet were regarded the best wear resisting plastic all over the world,The mortar abrasion index of UHMWPE sheet is only 1/5 of PA66,1/10 of HDPE & PVC.1/7 of carbon steel ,1/27 of brass.

2,Excellent impact resistance

The impact resistance of UHMWPE sheet is 2times higher than PC,5times than ABS and ten times than POM and PBTP,

3,Excellent self-lubrication

The self lubrication of uhmwpe sheet is 0.01-0.22,to be used as liner sheet,could greatly improve the operation efficiency and avoid material adhesion .

4,Chemical resistance

UHMWPE sheet could resist nearly all the chemical material,effectively protect the equipment and metal into corrosion and rusty

5,Lower density and excellent mechanical property

The density of UHMWPE lower than PTFE by 56%,could easy to carry and install

6,Lower cost

The price of UHWMPE is lower than other engineering plastic sheet,50% lower than PTFE and PU sheet

7,Eco-friendly

UHMWPE sheet could be recycled and zero-pollution to environment

The parament of UHMWPE sheet
