Golf cart rechargeable 18650 12v 20ah li-ion battery pack
0 likes
China [CN] |
1 |
Use high quality Seiko PCM |
|
2 |
Use high end battery cells imported from Japan and Korea |
|
3 |
Customizable |
|
4 |
Low self discharge rate |
|
5 |
long cycle life |
|
6 |
Environmental material |
|
7 |
Factory price&High quality |
|
8 |
Considerable service |
|
9 |
Safe and reliable |
|
10 |
OEM acceptable |
| 1 |
Battery cell model |
18650 |
|
2 |
Combination |
3S7P+PCM |
|
3 |
Nominal voltage |
11.1V |
|
4 |
Nominal capacity |
20Ah |
|
5 |
Standard discharge current |
0.2C |
|
6 |
Max discharge current |
1C |
|
7 |
Standard charge current |
0.2C |
|
8 |
Fast charge current |
0.5C |
|
9 |
Inner resistance |
82mohm |
|
10 |
Over discharge cut off voltage/series |
2.4 ± 0.06V |
|
11 |
Over charge protection voltage/series |
4.25± 0.03V |
|
12 |
Discharge working temperature |
-20-60°C |
|
13 |
Charge working temperature |
0-45°C |
|
14 |
Recommended storage temperature |
23 ± 5°C |
|
15 |
Flow value |
29.5A |
|
16 |
Weight |
about 1.1kg |
|
17 |
Size |
L*W*H=130*56*69.5mm |
The series of 9.6&V&11.1V lithium ion batteries can be widely used in:
Solar street light, communication equipment, vehicle terminal, GPS locator, dresser, loudspeaker box, mobile lighting products, stage lights, LCR gravimeter, grass cutter, back-up source, detectoscope, ultrasound equipment, engineering detectors,...
Our certificates of some batteries for reference
Click enlarge Image
