dynamic focus laser engraving system for LGP
Posting date : Aug 12, 2016
Membership
Free Member Scince Aug 11, 2016
FOB Price
USD12000/set
Min. Order Quantity
1 set
Supply Abillity
100 sets/month
Port
Shanghai
Payment Terms
T/T
Package
standard exported wooden case
Keyword :
Category
Contact
Terry Liu
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Feeltek
Model Number
C30
HS-CODE
8456-10
Package & Delivery Lead Time
Package
standard exported wooden case
Delivery Lead Time
5 working days
Patent
No. of Patent
201410461326.4,201420521219.1,2014R11S138204
Patent Name
3D surface and 3 axis dynamic focus ,and Lenmark software
Type of Patent
design patent
Start Date
2014-01-01

Detailed Description

Products application

The main products of FEELTEK includes 3 axis systems in C serial and F serial,wide field laser marking system , 3D surface &relief engraving system, laser pattern marking on moving walk piece based on visual position system, laser manufacturer by adding and removing material , 3D scanning and overall solution which integrated with lasers.
So , specifically , our product can do the works of die mould making , laser cleaning ,denim laser washing , 3D surface engraving ,LDS , LGP and visual positioning . And many other work of engraving .

C30

Features
Unique optical path design with low optical loss and high efficiency
Smallest spot diameter and outstanding mark quality
Variable marking area up to 1600 mm x 1600 mm

General specifications
Serial
C30pro
X/Y axis Galvanometer
CTI
Z axis Galvanometer
CTI
Lens
II-VI
Control card
CTI
Software suite
Lenmark-3D or Lenmark-3DS (optional)
Power supply
Control card
Environmental requirement
Input Voltage
170~264 VAC
Input interface
XY2-100 Protocol
Ambient temperature
0℃ ~ +40℃
Output Voltage
24 VDC
Output interface
USB
Storage temperature
-10℃ ~ +60℃
Current
10 A
Laser type
RF laser
Humidity
≤ 75 % non condensing

Specifications for deflection unit
Specifications for optics
Scan angle (°)
±11.25
Aperture size (mm)
30
Repeatability (urad)
8
Laser
CO2
Max. Gain drift (ppm/K)
100
Wavelength (nm)
10600
Max. Offset drift (urad/K)
30
Coating
AR Coating
Long-term drift over 8h (mrad)
0.5
Specifications for structure
Maximal processing speed (mm/s)
4500 (No deformation)
Weight (Kg)
20
Step response (ms)
≤0.4
Dimension [L×W×H] (mm)
616×200×219




Field size & Spot diameter
Field size (mm)
300×300
400×400
450×450
500×500
600×600
750×750
800×800
1200×1200
1600×1600
 Spot diameter 1/e2(mm)
0.230
0.280
0.310
0.330
0.390
0.460
0.490
0.760
0.970



Key advantages
Hardware
Unique optical path design based on laser beam characteristics, low optical loss with 20% efficiency increased.
Rapid response with high speed THK guide rail of Z axis.
High stability with CTI galvanometer.

Software
Provide application-specific interfaces to production line.
Optional 3D engraving software, easily achieve surface marking and 3D relief.

Technical support
Offer complete technical service with self-design hardware and software.
Provide the best spare parts under same price or same configuration.

Customer service
On-site technical training is provided for first-time customer.
Off-site technical engineer training is offered for regular customer.
