bucket chain dredger for lake river sand dredging
0 likes
China [CN] The gold mining bucket dredger use the buckets, driven by guide wheels on continuous rotation on the bucket bridge, so the bucket could dredge mud and sand to the water above, then into the separating system, solids larger than 10 mm will go into the tail-box, tailing discharged to place far away from gold dredger. Less than 10 mm of material from the flow channel into the Gold Sands separation system, based on the difference between the relative density of sand and gold, gold will fall into the bottom since of the high density,sand and other material will float on the surface,and discharged to the tail system by water.The gold separating equipment attached with the bucket gold dredger is decided by the detail condition of the mine,such as the type and shape of the gold;the percentage of the material smaller than 5mm etc. Every customer may have different request according to their own situation,and we can offer customized service,site investigation and testing are also available.
|
Product Name:
|
Gold Mining Bucket Dredger
|
|
Application:
|
Gold mining from river
|
|
Max Dredging Depth:
|
15m
|
|
Working Capacity:
|
150 m3/hr
|
|
Draft:
|
0.5m
|
|
Bucket Volume:
|
0.06m3
|
|
Bucket Quantity:
|
76 pcs
|
|
Color
|
Customized
|
Qingzhou Julong Environment Technology Co.,Ltd,has been devoted in Gold dredger,land gold mining equipment,cutter suction dredger,sand suction dredger,and water weed harvester and some other water environmental equipment for more than 20 years. And now we have 2 factories,one is for complete machine,other one is for accessories and spare parts,and we have a new factory is under building,which is floor area more than 20 acre.
1. Need to know about the working river,know much will be better;
2. How deep you want to dredge? It means the dredging depth of the dredger;
3. What's your request for the capacity of the dredger? How many cubic meter per hour do you want?
4. What's the main material in the river? Sand,clay,stone etc.
