High frequency transformer nanocrystalline cores
Posting date : Apr 26, 2016
Membership
Free Member Scince Mar 12, 2016
FOB Price
negotiable
Min. Order Quantity
100
Supply Abillity
100000
Port
Shanghai; Ningbo
Payment Terms
FOB
Package
customization
Keyword :
Category
Contact
Zhong
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
EHC
HS-CODE
8543-70
Package & Delivery Lead Time
Package
customization
Specifications
Type of Certification
ISO9001
Reference no.
00213Q13525ROS
Name.
ISO9001
Issued By
CQM
Start Date (validity period)
2013-06-21
End Date (validity period)
0000-00-00

Detailed Description
Transformer is irreplaceable in the power supply system. It has the following main functions: Electrical isolation;To realize the voltage rise or fall by different variety; High power rectifier vice edge phase shift is different, beneficial ripple coefficient decreased; Magnetic coupling transmit energy; Measure the voltage and electricity. Selection of nanocrystalline materials makes the transformer smaller volume, lower temperature and higher efficiency at the same time. Under 50 KHZ high-power switching power supply, nanocrystalline is the optimal choice of material of transformer.
Part No
Dimensions(mm)
AL(uH)
OD
ID
HT
10kHz0.3V
E107B05R05020
50
32
20
92
E107B05R06420
64
40
20
97
E107B05R07020
70
40
20
110
E107B05R07125
71
39
25
152
E107B05R08020
80
50
20
98
E107B05R08025
80
50
25
114
E107B05R10020
100
60
20
102
E107B05R10025
100
50
25
152
E107B05R10530
105
60
30
131
E107B05R10540
105
60
40
200
E107B05R12020
120
70
20
110
E107B05R12025
120
70
25
140
E107B05R12030
120
60
30
178
E107B05R12030
120
70
30
142
E107B05R12040
120
70
40
195
E107B05R13040
130
80
40
183
E107B05R13050
130
80
50
226
E107B05R13050
130
90
50
170
E107B05R13060
130
90
60
200
E107B05R14050
140
100
50
153
E107B05R14060
140
100
60
187
We can make customized dimension and specification.
