Fig: C100
Size Range: DN50-DN600
Allowable Operating Pressure: PN10,PN16
Face to face dimensions according to DIN3202-K3
Standard flange drilling to EN 1092 PN10/PN16, ASNI 125/150,JIS10K,AS2129 …
Fig.C400
Size Available : DN25-DN80 for thread end
DN50-DN300 for flang end
Face to Face: EN558-1 48 Series, DIN3202-F6
End Connection: BSP ISO 228-1
EN1092 PN10,PN16,
Working Pressure: PN10,PN…
Size Range: 1 1/2”-24”
Maximum Temperature: 80℃
Valve design: AWWA C509,AWWA C515
Face to face: ANSI B16.10.
End Flange: ANSI B16.42.
Hydraulic test according AWWA C509
Operator: Hand wheel, Gea…
Size Range: DN40-DN600
Allowable Operating Pressure: PN10,PN16,PN25
Maximum Temperature: 80℃
Valve design: BS5163,EN1074
Face to face: BS5163, EN558-1 Series 3.
End Flange: EN1092 PN10,PN16,PN25,…
Size Range: DN40-DN600
Allowable Operating Pressure: PN10,PN16,PN25
Maximum Temperature: 80℃
Valve design: DIN3352
Face to face: DIN3352 F4,F5, EN558-1 14,15 Series
End Flange: EN1092 PN10,PN16,…
