IEC60068-2-6 JJG189-97 Electrodynamic Vibration Generator Test Table
Posting date : May 06, 2021
Membership
Free Member Scince Oct 24, 2013
FOB Price
1
Min. Order Quantity
1
Supply Abillity
10
Port
Shanghai
Payment Terms
TT
Package
Wooden cases
Keyword :
Category
Contact
Jacky
Selling Leads Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
LISUN
Model Number
LVD-100KG
HS-CODE
-
Package & Delivery Lead Time
Package
Wooden cases
Delivery Lead Time
30
Detailed Description
LVD-100KG/LVD-100KG-6D Electrodynamic Vibration Generator Test Table  is according to IEC 60068, IEC68-2-6, JJG189-97, GB/T13309-91, GB2423 and other relevant standards.

• LVD-100KG: Combined the Vertical and Longitudinal total 4 directions in one test table.
• LVD-100KG-6D: Combined the Vertical, Level and Longitudinal total 6 directions in one test table.

Measurements:
Sine Wave, Frequency Modulation, Sweep Frequency, Programmable, Frequency Doubling, Logarithm, High Acceleration speed, Amplitude Modulation, Time Control, Full-function Computer Control, simple and easy to set the acceleration and amplitude.

Specifications:
• Vibration table size: 500*500mm (Other size can be designed)
• Vibration: 0~5mm (Adjustable range P-P). Vibration waveform: sine wave (half wave and full wave). Acceleration speed: 0~20g (Adjustable)
• Maximum test load capacity: 100kg
• Accuracy: Frequency can be displayed to 0.01 Hz. Precision: 0.1 Hz.
• Sweep frequency function (1~600Hz): (Upper frequency, Lower frequency, Time range) It can set real standard arbitrarily to sweep frequency back and forth
• Programmable Function (1~600Hz): It can set 15 segments in one test with different parameters (frequency/amplitude/time/acceleration), and it can be recycled
• Frequency doubling function (1~600Hz): 15 segments multiplied-increase:
1)Low to high frequency
2)High to low frequency
3)Low to high and then to low frequency, it can be recycled
• Logarithmic function (1~600Hz), 3 modes of logarithm/can be recycled:
1)Lower to upper frequency
2)Upper to lower frequency
3)Lower to upper and then to lower frequency
• Measuring instrument: To display amplitude, acceleration speed and the maximum acceleration speed
https://youtu.be/4BJOJ7M7EqM
