IEC60529 DIN40050 IP5K0 Dustproof Testing Machine for IP5X and IP6X
Posting date : May 06, 2021
Membership
Free Member Scince Oct 24, 2013
FOB Price
1
Min. Order Quantity
1
Supply Abillity
10
Port
Shanghai
Payment Terms
TT
Package
Wooden cases
Keyword :
Category
Contact
Jacky
Selling Leads Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
LISUN
Model Number
SC-015
HS-CODE
-
Package & Delivery Lead Time
Package
Wooden cases
Delivery Lead Time
30
Detailed Description

SC-015 Dustproof Test Chamber (Sand Dust Test Chamber) is applied to physical and other related performance tests for electronic and electrical products, lamps, electrical cabinets, electrical components, automobiles, motorcycles and their parts and other products under simulated dust climate conditions. After the measurement, it is judged whether the performance of the product meets the requirements through verification, so as to facilitate the design, improvement, verification and factory inspection of the product. Comply meets IEC60529:1989 +A1:1999 +A2: 2013 <Degrees of protection provided by enclosures (IP Code)>,IEC60598-1GB2423.37-89 (Test L: dust test methods), GB4208, GB/T 4942.2-93(protective casing grade of low-voltage apparatus), GB7000.1 <Luminaires Part 1: General Requirements and Tests> 9.2.1, 9.2.2 and Figure 6, DIN40050 and IP5K0. It is applicable to the IP5X and IP6X dustproof test of the products.

[caption id="attachment_5634" align="aligncenter" width="558"] IEC60529[/caption]

Product Model:

Model Number Working Room Size (mm) Remark
SC-500 700*800*900 Single door structure
SC-800 800*800*800
SC-010 1000*1000*1000
SC-015 1000*1500*1000 Double door structure
SC-020 1000*2000*1000

Specifications:
• Temperature range: RT+10~50℃
• Standard wire warp of metal net: 50um; Standard spacing between wires: 75um
• Test dust: dry talc powder; Talc powder dosage: 2~4kg/m; Dust reduction method: free dust reduction
• Total test time: 0~999H (adjustable); vibration time: 0~999H (adjustable); timing accuracy: ±1 second
• Vacuum: 0~10Kpa (adjustable); Pumping speed: 0~4800L/H (adjustable)
• Power supply of test samples: single-phase 220V/50Hz or 100V/60Hz
• Safety protection function: leakage protection, short circuit protection
• The shell is made of domestic high-quality steel plate, and the surface is sprayed with paint, which is beautiful and durable.
• The inner box, sample rack, etc. are made of stainless steel plates to ensure that they will not rust for a long time.
• There is a transparent observation window (toughened glass material) on the door, and an LED lighting lamp is installed in the box to facilitate the observation of the internal test situation.
• There is a device for replacing dust at the bottom of the device, which can easily 100% replace the used dust.
• A special device is installed to ensure that the dust does not stick to the wall and condense. The working time of the device is adjustable, and it can work automatically and alternately.
• There is a suction pipe in the box, which can complete the vacuum action on the sample (require the sample to reserve the suction hole position).
• Dustproof test chamber control system: 7-inch touch screen + Panasonic PLC. The dust blower, dust  vibration and total test time can be controlled separately. This controller has the following various arbitrary setting control functions:
1. Dust blowing time (stop, blowing): can arbitrarily choose any of continuous and periodic dust blowing time to setting;
2. Vibration time: vibration and stop vibration time are automatically alternated;
3. Preset test time: the maximum test time is 99 hours and 59 minutes;
• Heating system: The circulating air duct is equipped with a heater to heat the dust to avoid dust condensation. The heat of the muffler mica sheet heating ring is safe and stable.
• Vacuum system: equipped with vacuum pump, vacuum pressure, air filtration, flow meter, pressure regulating triplet, connecting pipe.

https://youtu.be/XRBB8yvGAgo
