2015 new technology grain milling machine price
Posting date : Nov 14, 2015
Membership
Free Member Scince Nov 13, 2015
FOB Price
200000
Min. Order Quantity
1 SET
Supply Abillity
300 sets per year
Port
tianjin shanghai
Payment Terms
T/T L/C
Package
container
Keyword :
Category
Contact
Grace Shi
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
Goldrain
Model Number
6FTF-80
HS-CODE
2302-30
Package & Delivery Lead Time
Package
container
Delivery Lead Time
within 30 days
Specifications
Type of Certification
1
Reference no.
1
Name.
1
Issued By
1
Start Date (validity period)
0000-00-00
End Date (validity period)
0000-00-00
Scope
1

Detailed Description
2015 new technology grain milling machine price

80TPD wheat flour milling machine

Parameters
Dry method Wet method
Technical for cleaning system:Three sieves,two beating,two removing stone, two magnetic selecting.

Technical for flour system:Eight Milling,two Six-bin square sifter, one Purifier make up of 4B、5M、1S and ,and 3Bf, (finess) 2 Bran brushers.
Technical for cleaning system:Three sieves,two beating,Two removing stone, three magnetic selecting ,one washing.

Technical for flour system:Eight  Milling,Two Six-bin square sifter, of 4B、6M、1S.1Tand 2Bran finishers.
1.Total length of the roller:9600mm
2.Capacity(wheat/24h): 80T/24h
3.Flour extraction: 72~80%
4.Flour quality: obey the people’s republic of China’s GB1355-88 starndard
5.Power supply:240kW
6.Total weight of the equipment :65T
7.Dimension of the factory: 32000×10000×11000mm(Tripod structure)
8.Container: 40’×4
1.Total length of the roller:9600mm
2.Capacity(wheat/24h): 80T/24h
3.Flour extraction: 75~82%
4.Flour quality: obey the people’s republic of China’s GB1355-88 starndard
5.Power supply:296kW
6.Total weight of the equipment :30T
7.Container: 40’×8



1.Cleaning
Cleaning begins with screening to remove coarse and fine materials and the grain is separated by size, shape and weight. The finished product, whole pure wheat, is then passed into conditioning bins.

2. Conditioning
Conditioning takes place before milling to produce a uniform moisture content throughout the grain. Moistening helps to prevent breakup of the bran (hard outer layer) during milling and improves separation from the floury endosperm (the mass that forms the white flour of the grain).

3. Gristing
After conditioning, different batches of wheat are belended together (gristed) to make a mix capable of producing the required flour quality.

4. Milling
Essentially this is the separation of bran and germ from the endosperm and the reduction of the endosperm to a uniform particle size (flour). This is done by a sequence of breaking, grinding and seperating operation.

5.Packing
Packing is the final procedure, pack the flour or other products into bags of different size. After packing well, the bags will be stacked in order and ready for selling or using. Manual packing and auto-packing method will be available according to customers requirements.

6. Controlling
All the above procedures are automatically and controlled by PLC, only one or two person is needed for operation, it can save your labor and save time a lot.


http://www.goldraingroup.com/Flour-Milling-Machin.html
