6.1 Forming Rack:14 Pairs,and add Rub-roll, To make sure the surface profile no scratches.
6.2 Side Panel:T.18mm ,A3 steel Heavy duty 。
6.4 Roller material:overall quenching, hardness HRC50-55 ℃.
6.6 Motor power:4KW。
6.6 Main Roller :¢65mm,45#。
6.7 Equipment base: 30 # H type using welded steel plate.
6.8 Transmission: chain drive.
6.9 Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.
Storage rack roll forming machine Main Features:
1. Fully automatic and CNC pipe bending machine.
2. Equipped with servo motor programmable axis,2axis 3 axis, 4 axis or 5 axis...
3. Feeding: servomotor drive; Rotation: servomotor drive
4. Bending: hydraulic and encoder control; Servomotor with reducer.
5. Imported hydraulic system and PLC unit.
6. Automatic lubrication system for moving areas.
7. Self-diagnostic system, detecting the error immediately.
8. Multiple groups pipe-bending information storage.
9. Electric cabinet cooling fan and the hydraulic cooling system ensure the equipment long-time work stably under the high temperature.
10. Touch screen and human/machine interface control provide user friendly operations
No.
|
ITEM
|
PARAMETER
|
REMARK
|
|
1
|
MATERIAL
|
Type
|
Cold-rolled strip steel, galvanized sheet
|
|
T.(mm)
|
0.8-1.5mm
|
|
||
Yield Strength (Mpa)
|
Q235
|
|
||
2
|
Forming speed (m/min)
|
2-8m
|
Including hole
|
|
3
|
Forming main power (KW)
|
7.5KW
|
FYR
|
|
4
|
Hydraulic power (KW)
|
18.5KW
|
FYR
|
|
5
|
Bending machine (KW)
|
3 KW
|
|
|
5
|
Total Power
|
29 KW
|
FYR
|
|
6
|
Voltage
|
AC380V,50Hz,3P
|
|
