CE REPORT
Issued By
ECM
Start Date (validity period)
2015-03-12
End Date (validity period)
0000-00-00

Detailed Description
China highway guard rail roll forming machine manufacturer

Highway rail forming machine technology parameters
No.
ITEM
PARAMETER
REMARK
1
MATERIAL
Type
Cold-rolled strip steel, galvanized sheet

T.(mm)
3.0-4.5mm

Yield Strength (Mpa)
Q250-300

2
Forming product Width
310/506mm

3
Forming speed (m/min)
8-12m
Including hole
4
Forming main power (KW)
18.5KW*2PCS
FYR
5
Hydraulic power (KW)
30 KW
FYR
6
Voltage
 AC380V,50Hz,3P


Highway guard rail process
Uncoiler →Guide device→Straightening→Hydraulic press breach device  → roll forming machine → hydraulic punch →shear device (including knife)→ finished product rack

 Hydraulic hole punching system
3.1 Function:Hydraulic punch breach  (Mould 1 set)
3.2  Structure: set the length, automatic length measurement, automatic positioning reaches the set distance stop action , hydraulic cylinder driven punching die, stamping automatic shutdown.
3.3 Hydraulic system working pressure:16MPa
3.4 Hydraulic station:30KW( Hydraulic punch hole/shear use same station)

Main Roll Forming machines  (for panel width 490mm )

6.1  Forming Roller:19 stations,and add Rub-roll, To make sure the surface profile no scratches.
6.2 Gateway Panel:T.50mm steel,   Heavy duty 。
  6.3  Rolling speeding: 8-12 m/min
      6.4  Roller material:GCr15,overall quenching, hardness HRC56-62 ℃.
6.5  Motor power:18.5KW*2PCS。
6.6  Main Roller :¢95mm,45 #。
6.7  Equipment base: 45 # H type using welded steel plate.
6.8  Transmission: Gearbox drive.
6.9 Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.

Hydraulic Punch Machine /Follow shear
    6.1 Hydraulic Punch machine
   6.2  Follow shear (Cut style):Hydraulic cut(No blanking),Machine non-stop can cut product.
        Knife material:Cr12,quenching hardness of up to HRC56-58 degrees.
Machinery Flat collect rack ,2m*2pcs
Guard rail machine Electrical control system
The entire line imported PLC control, LCD touch screen, man-machine interface. People interact with the PLC. Operator setting the program to run automatically (programmable control) and control process monitoring, production line operator control and modify the control parameters, and real-time monitoring the equipment status & parameters and fault indication. Workpiece length digital setting, adjustable length can be adjustable as well. Real-time monitoring of equipment operating status and fault indication.
Operation manual / automatic two styles. With manual and automatic switching function: In the manual mode, can be stand-alone operation, easy maintenance; In automatic mode, carry out full production run, in order to start; across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operating personnel Safety.
** The main components of the brand:
PLC control system: Siemens
Inverter: Taiwan Shilin
Encoder: Omron
Touch screen: Siemens
Some components are Schneider brand devices.





No.
Machine name
QTY
REMARK
1
Uncoiler
1

2
Hydraulic machine
1
With mould
3
Guide device
1

4
Forming machine
1

5
Hydraulic machine
1
With mould
6
Follow Shear
1
Including knife
7
Collect rack
1

8
Control system
1



Brand

No.
Name
Manufacturer
1
Motor & Reducer
Domestic brands
2
The main key bearing
Domestic brands
3
Inverter
Shilin
4
PLC Systems
Siemens
5
Low-voltage electrical
Schneider
6
Encoder
Omron
7
touch screen
Siemens
8
Hydraulic system
Domestic brands
