customized precision current transformer
Posting date : May 09, 2016
Membership
Free Member Scince Mar 12, 2016
FOB Price
negotiable
Min. Order Quantity
10
Supply Abillity
100000
Port
Shanghai; Ningbo
Payment Terms
negotiable
Package
can be customized
Keyword :
Category
Contact
Zhong
Selling Leads Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
EHC
Model Number
CTG
HS-CODE
8543-30
Package & Delivery Lead Time
Package
can be customized
Specifications
Type of Certification
ISO9001
Reference no.
00213Q13525ROS
Name.
ISO9001
Issued By
CQM
Start Date (validity period)
2013-06-21
End Date (validity period)
0000-00-00

Detailed Description
CTG series are precision current transformers, the precision grade is 0.1 class,they are widely used in grid electricity measurement meter and intelligent power system;

error range

accuracy class

Current ratio error%

 phase error

Rated current percentage value

Rated current percentage value

1

5

20

100

Imax

1

5

20

100

Imax

0.2

≤0.4

≤0.2

≤0.2

≤0.2

≤0.2

≤30

≤15

≤10

≤10

≤10

0.1

≤0.2

≤0.1

≤0.1

≤0.1

≤0.1

≤15

≤8

≤5

≤5

≤5

Selection of Reference
Model
Rated Pr.Curren In(A)
Max.Current Imax(A)
Rated Sec.Current (mA)
accuracy
LR(Ω)
CTG2mA/2mA0.1S15Ω
2
---
2
0.1
15
CTG5(60)A/2.5mA0.1S15Ω
5
60
2.5
0.1
15
CTG5(80)A/2mA0.1S15Ω
5
80
2
0.1
15
CTG5(100)A/2.5mA0.1S15Ω
5
100
2.5
0.1
15
CTG10(150)A/2.5mA0.1S15Ω
10
150
5
0.1
15
