TL 780 Auto Hot Gold Foil Stamping Machine For Paper Box
Posting date : Feb 03, 2018
Membership
Free Member Scince Feb 03, 2018
FOB Price
55000-65000
Min. Order Quantity
1
Supply Abillity
30
Port
ningbo
Payment Terms
T/T L/C
Package
wooden case
Keyword :
Category
Contact
CLICK ZHANG
          0 likes
Product Detail
Company Info

Quick Detail
Place of Origin
China [CN]
Brand Name
shiwei
HS-CODE
8443-39
Package & Delivery Lead Time
Package
wooden case
Detailed Description
TL 780 Auto Hot Gold Foil Stamping Machine For Paper Box





1. The Auto Hot Gold Foil Stamping Machine For Paper Box is designed for the Hot Foil Printing, Hot Foil Stamping, Die Cutting, Embossing Convex and Creasing etc technologies, its suitable for paper, cardboard, plastic sheet and so on. It can finish feeding, Hot Foil Printing, collecting work cycle automatically.2. The Auto Hot Gold Foil Stamping Machine For Paper Box is composed of four parts: main motor, Hot Foil Printing, auto feeder and electric equipment. The motor's main transmission is by bend shaft structure driving the platen running up and down, plus the pressure adjusting structure, coordinate to finish Hot Foil Printing or die cutting job.3. The electrical parts are composed of main motor control, feeder/collect control and foil feeder control and so on. The whole machine is controlled by micro processor.4. The Auto Hot Gold Foil Stamping Machine For Paper Box Control is equipped with the automatic lubrication system.



MACHINE SPECIFICATIONS
Model
TL 780 Automatic Hot Foil Stamping Machine
Max. sheet size
780*560 mm
Min. sheet size
280*220 mm
Max. feeding pile height
800 mm
Max. delivery pile height
160 mm
Max. working pressure
110 T
Main motor power
12 kw
Air pump displacement
40 m³ / h
Paper range
100 - 2000 GSM
Max. mechanical speed
1500 S/H Paper less than 150 GSM2500 S/H Paper More than 150 GSM
Machine noise
Less than 81 db
Electric plate power
8 kw
Overall machine dimensions
3700*1910*2200 mm

1. High quality electric partsOver half of the machine electric parts use high quality international brand which could keep the machine in very good condition, running smooth and stable.



2. Strong metal machine bodyA stronger body that made by high strength metal it could offer more capacity, that makes machine afford more cutting speed.



3. Automatic Paper Feeding with servo motor controlTried about feeding paper by manual? Try our automatic paper feeding system, low staff cost, feeding full automatically, and controlled by high accuracy servo system.



4. PLC and SensorPLC that is short for “programmable Logical controller”, which could make sure that every working part gets perfect cooperation when running complex producing process. Most of them that we use for our machines is PANASONIC, MITSUBISHI and other international brand with WE!NVIEW touch screen. Also compare with the sensor from OMRON covered the machine body to keep safe of the equipment and operator.

Company

Manufacturer for die cutting machine and hot foil stamping machine since 1997

We believe " once you put your name on your equipment, forever people would remember it", CE, IEC, ISO 9001, we prepare everything that required, anyway Quality is the first core value of our company !!!

More than 20 years' time, as wide as 80 countries.

In last two decades, we have sent our machines to more than 80 countries. Middle East, Europe, Asian, Africa, South and North America, people from various countries, language in different types, we met them and won their friendship. With us, your money is safe, your business is safe !!!
